MORE THAN JUST A MONUMENT
When people stand before an iconic statue, they admire its scale, symbolism, and craftsmanship. Few pause to consider the invisible engineering that allows such colossal structures to stand safely against gravity, wind, seismic forces, and the passage of time. While structural steel often forms the internal skeleton, equally critical is the reinforced concrete foundation, pedestal, and core, where high-performance TMT reinforcement provides the strength, ductility, and durability required of structures expected to last a century or more.
According to Bhushan Nahire, General Manager – Design, TPF Engineering Pvt. Ltd., a statue is “first an artistic creation and then a structural system,” and the engineer’s task is to build an internal framework that supports an irregular external form without compromising the sculptor’s vision.
BUILDING AN ICON STARTS BELOW GROUND
Before a statue rises into the skyline, engineers begin several metres below the ground. Unlike conventional buildings, where loads are carried gravity-first through columns, beams, and slabs, the foundation of a monumental statue is governed primarily by overturning moment rather than gravity load. Because of the statue’s height relative to its footprint, wind and seismic forces generate significant uplift, and piles and pile caps must be designed to resist both compression and tension, “with robust pile-to-cap connections and adequate development lengths,” Nahire explains.
Pile caps on these projects behave less like conventional beams and more like deep transfer elements, which is why Nahire designs their reinforcement using Strut-and-Tie Modelling, as recommended in Annex B of IS 456, to ensure efficient transfer of concentrated forces. Differential settlement between the central core and the peripheral foundations is controlled just as carefully, since even minor settlement can introduce additional stress into the statue and its cladding above.
Layered on top of the foundation logic are the statue’s own structural irregularities. Extended arms, inclined heads, and asymmetric forms create eccentricities, torsion, and bending moments that don’t exist in a conventional building, and slender statues, Nahire notes, “behave more like towers than buildings,” which makes dynamic wind and seismic behaviour central to the design rather than a secondary check.
REINFORCEMENT BEYOND STRENGTH
For structures meant to last 100 to 200 years, Nahire treats reinforcement selection as something well beyond satisfying the minimum requirements of IS 1786. He generally specifies Fe 500D or Fe 550D reinforcement, since the “D” grade provides superior ductility, which he considers “essential for seismic performance and force redistribution.” Particular attention goes to the Fy/Fu ratio and uniform elongation, ensuring the steel can strain-harden reliably without compromising capacity design principles.
Chemical composition matters just as much as grade, in his account. He prefers a low Carbon Equivalent to improve weldability and ductility, especially where complex reinforcement layouts call for site welding, and keeps sulphur and phosphorus content below code limits for structures in marine or industrial environments, reducing the risk of both corrosion and brittle failure.
Corrosion protection, bond performance, and traceability round out his checklist. Depending on exposure, he turns to epoxy-coated bars, stainless steel reinforcement for critical members, or corrosion-inhibiting admixtures paired with low-permeability concrete, and insists on periodic third-party inspection to confirm bar geometry meets IS 1786. For landmark structures specifically, he expects “complete traceability,” with every batch backed by mill test certificates, heat numbers, and independent testing at NABL-accredited laboratories.
What Engineers Look For In Reinforcement?
- Ductility (Fe 500D / 550D grade)
- Controlled Fy/Fu ratio and uniform elongation
- Low Carbon Equivalent for weldability
- Corrosion protection suited to exposure
- Full batch traceability and third-party testing
DESIGNING FOR A HUNDRED YEARS
Statues are not ordinary buildings, Nahire points out, and durability drives nearly every decision once the structural system is in place. The primary threats to long-term performance, he explains, are “carbonation, chloride ingress, freeze-thaw action in cold regions, and alkali-silica reaction,” all of which can quietly deteriorate concrete and trigger reinforcement corrosion if left unaddressed at the design stage. To counter this, he relies on low water-cement ratios, high-quality concrete, increased reinforcement cover, and supplementary cementitious materials such as GGBS or fly ash, adding further corrosion protection in coastal or aggressive environments.
Crack control gets equal weight in his process, for both durability and appearance. While IS 456 sets crack width limits by exposure condition, Nahire adopts a tighter design limit of around 0.15 mm for exposed surfaces on monumental structures, achieved through closer bar spacing, adequate shrinkage and temperature reinforcement, and carefully detailed construction joints, so that, as he puts it, “any cracks remain fine, stable and durable throughout the service life.”
His responsibility, he adds, doesn’t end at construction. Where appropriate, he builds in Structural Health Monitoring systems, including strain gauges, accelerometers, corrosion sensors, and weather stations, which “provide valuable information on structural behaviour, environmental effects and deterioration trends,” allowing preventive maintenance before damage becomes visible.
LESSONS FROM MONUMENTAL PROJECTS
Drawing on projects including the Statue of Unity and the Spring Temple Buddha, Nahire points to a few lessons he considers non-negotiable for future landmark projects. Wind tunnel testing, in his view, should begin “during the concept design stage,” not as a late validation step, since even minor shape refinements at that point can meaningfully reduce wind loads and produce more efficient foundations and reinforcement. Construction-stage analysis deserves equal attention, he says, because temporary cantilevers and incomplete load paths during erection can produce stresses that exceed those in the finished structure.
He is equally firm on planning for the decades after completion: internal access routes, maintenance platforms, and inspection openings need to be designed in from the start, “so that critical structural components remain accessible throughout the service life of the monument,” rather than retrofitted once problems surface.
THE SSMB TAKE
Monumental statues are judged, first, by what they look like. Wind loading, foundation depth, reinforcement grade, and crack-width tolerances rarely make it into the conversation, yet by Nahire’s account, they are the decisions that determine whether a monument survives its first decade of monsoons, let alone its intended century or two of service. What stands out across his answers is how little of that discipline is visible in the final structure: a pile cap resisting uplift instead of just carrying weight, a 0.15 mm crack limit instead of the code minimum, a sensor network quietly logging strain long after the ribbon-cutting is forgotten. None of it competes with the statue for attention, and none of it is optional either. The steel that holds up history, it turns out, is also the steel history never gets to see.
“Every monumental statue is a unique engineering challenge requiring advanced analysis, close collaboration between architects and structural engineers, and project specific design solutions.” Â – Bhushan Nahire, General Manager – Design, TPF Engineering Pvt. Ltd.
